Issue Resolution
Background
Error 35 occurs. The opto-board has either failed or could have been contaminated with oil. The black plastic unit is a “Slotted optical switch” and contains a light source (LED) on one side (S) and a detector on the other. If contaminated with oil, the oil will prevent the light from reaching the detector.
Resolution
Replace the opto-board. Download the following PDF for detailed instructions on replacing the opto-board.
Parts Required
| Part Number | Description | |
|---|---|---|
| CS-PPOD-V2 |  |
CINRG Syringe Pump Opto Detector (Version 2) |
Service Media
CINRG-CS-APC-2-SUPPORT-ERROR-35
CINRG Support - Opto-board replacement instructions bulletin.
